300-610 practice questions 1–10

1. Question 1 · 207 in bank

   What is an advantage of using OTV as compared to VPLS for data center redundancy?

   • Aprevents loops on point-to-point links
   • Bprovides head-end replication
   • Cuses a proactive MAC advertisement
   • Dprovides full-mesh connectivity

   Show answer

   Answer: A

   Next question

2. Question 2 · 207 in bank

   Which multicast rendezvous point redundancy mode is valid for Bidirectional PIM?

   • AEmbedded RP
   • BPhantom RP
   • CMSDP
   • DPIM anycast RP

   Show answer

   Answer: D

   Next question

3. Question 3 · 207 in bank

   An engineer deploys LISP VM mobility. Which feature is configured on the interfaces that have VM mobility enabled?

   • AIP redirects
   • Bflow control
   • Cproxy ARP
   • DHSRP

   Show answer

   Answer: C

   Next question

4. Question 4 · 207 in bank

   Select 2

   What are two advantages of using Cisco vPC over traditional access layer designs? (Choose two.)

   • Asupports Layer 3 port channels
   • Bdisables spanning-tree
   • Cno spanning-tree blocked ports
   • Duses all available uplink bandwidth
   • Emaintains single control plane

   Show answer

   Answer: CD

   Next question

5. Question 5 · 207 in bank

   What is a design consideration when implementing FSPF?

   • ARoutes are based on the domain ID.
   • BRoutes are based on the distance vector protocol.
   • CFSPF runs only on F Ports.
   • DFSPF runs on a per-chassis basis.

   Show answer

   Answer: A

   Next question

6. Question 6 · 207 in bank

   Select 2

   Which two features are provided by deploying an OOB management network in a Cisco Nexus data center? (Choose two.)

   • ALayer 3 path for monitoring purposes
   • BLayer 2 path for server traffic
   • CLayer 2 path for a vPC peer link
   • DLayer 3 path for vPC keepalive packets
   • ELayer 3 path for server traffic

   Show answer

   Answer: AD

   Next question

7. Question 7 · 207 in bank

   The management of the Cisco Nexus switches is provided over an isolated put-of-band network. The VDC feature is configured on the Cisco Nexus core switches. How is out-of-band management access provided for each VDC?

   • AAll the VDC have the same out-of-band IP address.
   • BEach VDC has a dedicated out-of-band Ethernet management port.
   • CEach VDC has a unique out-of-band IP address from the same IP subnet.
   • DEach VDC has a unique out-of-band IP address from different IP subnets among VDCs.

   Show answer

   Answer: C

   Next question

8. Question 8 · 207 in bank

   Select 2

   Which two configurations allow for routing traffic between two VDCs? (Choose two.)

   • AConnect the VDCs to an external Layer 3 device.
   • BCross-connect the ports between the VDCs.
   • CCreate VRF-aware software infrastructure interfaces.
   • DCreate a policy map in the default VDC that routes traffic between the VDCs.
   • ECreate interfaces in the VDC that can be accessed by another VDC.

   Show answer

   Answer: AD

   Next question

9. Question 9 · 207 in bank

   Which protocol prevents fiber failures from causing a Layer 2 loop in a dark fiber DCI?

   • ABFD
   • BUDLD
   • CMCP
   • DLLDP

   Show answer

   Answer: B

   Next question

10. Question 10 · 207 in bank

    Select 2

    What are two characteristics of VRF-Lite on the Cisco NX-OS platform? (Choose two.)

    • ALayer 3 interfaces can belong to multiple VRFs.
    • BVRF-Lite interfaces can be Layer 2.
    • COverlapping IP addresses are permitted on different VRFs.
    • DInterfaces that belong to VRFs can be physical or logical.
    • EVRF-Lite interfaces support MPLS.

    Show answer

    Answer: CD

    Next question
