Question 11 · 232 in bank
HOTSPOT - Your company has the divisions shown in the following table.
You plan to deploy a custom application to each subscription. The application will contain the following: ✑ A resource group ✑ An Azure web app ✑ Custom role assignments ✑ An Azure Cosmos DB account You need to use Azure Blueprints to deploy the application to each subscription. What is the minimum number of objects required to deploy the application? To answer, select the appropriate options in the answer area. NOTE: Each correct selection is worth one point. Hot Area:
This is an interactive task on the real exam — a drag-and-drop, hotspot or ordering question. There is nothing to select here, so the answer is shown below for reference.
Show the answer figure
Answer: See figure below
Explanation
Box 1: 2 - One management group for each Azure AD tenant Azure management groups provide a level of scope above subscriptions. All subscriptions within a management group automatically inherit the conditions applied to the management group. All subscriptions within a single management group must trust the same Azure Active Directory tenant. Box 2: 1 - One single blueprint definition can be assigned to different existing management groups or subscriptions. When creating a blueprint definition, you'll define where the blueprint is saved. Blueprints can be saved to a management group or subscription that you have Contributor access to. If the location is a management group, the blueprint is available to assign to any child subscription of that management group. Box 3: 2 - Blueprint assignment - Each Published Version of a blueprint can be assigned (with a max name length of 90 characters) to an existing management group or subscription. Assigning a blueprint definition to a management group means the assignment object exists at the management group. The deployment of artifacts still targets a subscription. Reference: https://docs.microsoft.com/en-us/azure/governance/management-groups/overview https://docs.microsoft.com/en-us/azure/governance/blueprints/overview
Source: Adapted from community discussion — Snownoodles
