Question 31 · 578 in bank
Refer to the exhibit. An engineer is trying to configure local authentication on the console line, but the device is trying to authenticate using TACACS+. Which action produces the desired configuration?
Show answer
Answer: D
Explanation
D sounds right: Example 2: Console Access Using Line Password Let's expand the configuration from Example 1 so that console login is only authenticated by the password set on line con 0. The list CONSOLE is defined and then applied to line con 0. We configure: Router(config)# aaa authentication login CONSOLE line In the command above: the named list is CONSOLE. there is only one authentication method (line). Once a named list (in this example, CONSOLE) is created, it must be applied to a line or interface for it to come into effect. This is done using the login authentication list_name command: Router(config)# line con 0 Router(config-line)# exec-timeout 0 0 Router(config-line)# password cisco Router(config-line)# login authentication CONSOLE https://www.cisco.com/c/en/us/support/docs/security-vpn/terminal-access-controller-access-control-system-tacacs-/10384-security.html
Source: Adapted from community discussion — CraigB83
